Waterstops

Flexible waterproofing for concrete joints

The way to a better waterstop.

Waterstops represent a critical component of any waterproofing system. Due to shrinkage and settling, the surfaces of a concrete cold joint will never perfectly conform to one another. Without a flexible barrier that can accommodate the imperfections  of concrete surfaces, water will have the opportunity to creep in through the seam.

Documents

Waterstop Product Document

Product Name Product Data Sheet
ADCOR® 500S
Product Data Sheet
AT System: SERVITITE® AT 200/SERVISEAL® AT 240
Product Data Sheet
PVC EDGETIE™
Product Data Sheet
SWELLSEAL® Mastic
Product Data Sheet
Products & Accessories

Products

  • Product Name
  • Description
  • Key Benefits
  • Applications Type
ADCOR® 500S
Description

A conformable, swellable polymer/butyl rubber waterstop strip that expands in contact with water.

Key Benefits
  • Controlled volumetric expansion
  • Conformable
  • Retains cohesive strength
Application Type
  • Construction joints in in-situ concrete structures
  • Casting new concrete against existing
  • Floor slabs cast against diaphragm retaining walls, steel sheet piles and secant piled walls
ADCOR® 500T
Description

ADCOR® 500T is a unique product that has been specifically developed to provide higher performance than conventional bentonite or swellable rubber waterstops.

Key Benefits
  • Controlled volumetric expansion
  • Conformable
  • Retains cohesive strength at both original and expanded volume
Application Type
  • Casting new concrete against existing
  • Joints between floor slabs and pile caps
  • Pipe penetrations through floors and walls
ADCOR® 550 MI
Description

ADCOR® 550MI is a combined active and passive waterstop system with built in redundancy for the secure sealing of concrete construction joints subject to hydrostatic pressure.

Key Benefits
  • Easy installation.
  • Non-polluting to ground water
  • Conformable
Application Type
  • Construction joints for in-situ concrete structures
  • Casting new concrete against existing concrete
  • Joints between floor slabs and pile caps
ADCOR® 550 T-MI
Description

ADCOR® 550 T-MI is a combined active and passive waterstop system with built in redundancy for the secure sealing of concrete construction joints subject to hydrostatic pressure.

Key Benefits
  • A hydrophilic outer sleeve
  • A filtration membrane outside the reinforced inner tube
  • A steel wire reinforced inner tube
Application Type
  • Construction joints for in-situ concrete structures
  • Casting new concrete against existing concrete
  • Floor slabs cast against diaphragm retaining walls, steel sheet piles and secant piled walls
ADCOR® Hydrophilic Waterstop 500T
Description

A conformable, swellable polymer/butyl rubber waterstop strip that expands in contact with saline and brackish water.

Key Benefits
  • Controlled volumetric expansion
  • Conformable
  • Retains cohesive strength at both original and expanded volume.
Application Type
  • Continuity of swellable waterstops at construction joint/movement joint intersections
ADCOR® Hydrophilic Waterstop 550 MI
Description

ADCOR® 550MI is a combined active and passive waterstop system with built in redundancy for the secure sealing of concrete construction joints subject to hydrostatic pressure.

Key Benefits
  • A hydrophilic outer sleeve
  • A filtration membrane outside the reinforced inner tube
  • A steel wire reinforced inner tube
Application Type
  • Construction joints for in-situ concrete structures
  • Casting new concrete against existing concrete
  • Floor slabs cast against diaphragm retaining walls, steel sheet piles and secant piled walls
ADCOR® Hydrophilic Waterstop 550 T-MI
Description

ADCOR® 550 T-MI is a combined active and passive waterstop system with built in redundancy for the secure sealing of concrete construction joints subject to hydrostatic pressure.

Key Benefits
  • A hydrophilic outer sleeve
  • A filtration membrane outside the reinforced inner tube
  • A steel wire reinforced inner tube
Application Type
  • Floor slabs cast against diaphragm retaining walls, steel sheet piles and secant piled walls
  • Joints between floor slabs and pile caps
  • Remedial ‘breaking out’ of concrete
AT System: SERVITITE® AT 200/SERVISEAL® AT 240
Description

AT System waterstops have been specially developed for water excluding and retaining structures such as basements, reservoirs, sewage treatment works, etc. The AT System is an important advance in concrete joint protection which combines Active Technology with the conventional mechanical properties of PVC waterstops.

Key Benefits
  • Increased security – combines advantages of PVC waterstop with active hydrophilic elements to provide maximum resistance to water pressure
  • Continuously active sealing – hydrophilic elements swell in contact with water to plug voids formed by normal concrete shrinkage
  • Prevents water tracking – location of active element is designed to prevent lateral migration of water along waterstop bulb
Application Type
PVC EDGETIE™
Description

PVC EDGETIE™ is an internally cast passive waterstop system manufactured in a range of sizes for sealing joints in concrete structures subject to water pressure.

Key Benefits
  • Proven profile - solid circular end bulbs promote better concrete compaction and simplifies site jointing
  • Flexible - will accommodate movement during construction and service life
  • Valve action - created by concrete shrinkage around end bulbs
Application Type
SERVISEAL®
Description

SERVISEAL® is a passive external PVC waterstop system manufactured in a range of sizes for protecting joints in concrete basements and sub-structures.

Key Benefits
  • Proven design
  • Flexible
  • External seal
  • Pliable
Application Type
SWELLSEAL® Mastic
Description

SWELLSEAL® Mastic is a one-component, polyurethane-based, solvent free, hydroswelling mastic, supplied in cartridges and aluminium sausages, for the sealing of construction joints and around pipe penetrations. SWELLSEAL® Mastic cures and swells in the presence of moisture.

Key Benefits
  • Solvent free
  • Flexible system
  • Easy application with standard caulking gun
  • Durable
Application Type
  • Sealing rough and smooth construction joints of in-situ cast concrete
  • Sealing joints between pre-cast segments
  • Sealing around steel H-beams
Overview

The GCP advantage

Our waterstops are specifically designed to resist job-site conditions while outperforming other solutions. These waterstops offer innovative technology options  to meet a wide variety of project needs. This includes tricky or problematic installations where technical finesse is required. No matter the project, we have a waterstop that’s ideal for the job.

Waterstop Solutions

Our solutions incorporate advanced materials that prevent water infiltration in ways that other waterstops can't.  Novel engineering technologies result in waterstops that conform more securely to concrete surfaces, last longer and provide more flexibility to contractors. For more information about these and other waterstop solutions, contact GCP today.

ADCOR®

An advanced hydrophilic waterstop that's compatible with all of our  industry-leading waterproofing membranes. ADCOR® is engineered to expand when it comes in contact with water. The material seals against concrete faces when encapsulated and resists water infiltration through a cold joint.

INJECTO® Tube Groutable Hose Waterstop System

An injectable waterstop system that provides a passageway for a variety of chemical grouts. The system is designed to be laid down before concrete is poured, but not injected until well after it has cured. This allows the cracks created by shrinkage during the curing process to fully open. The resulting interfaces and voids can then be permanently sealed.

TRIOject® Multiple Grout Injection Hose

Comprised of a three-channel PVC-hose, TRIOject® allows for multiple grout injections in a more durable enclosure. Each of the three grout channels contains micro holes that prevent water from getting in, but allow grout to escape. The system is protected by a steel mesh on top, as well as a foam pad on the bottom that conforms to the concrete surface.  Crucially, the three-channel TRIOject® design lets builders inject the same cold joint multiple times—a best-in-class solution for a critical or problematic application.
